With a wide 22mm rim profile that’s optimized for high-volume tires, this UST Road Tubeless wheel system Allroad from Mavic is built for adventure.

Proven performance and reliability: with the Allroad from Mavic

Perfect for riding on rough roads, gravel or dirt, it gives you the smooth-riding performance of tubeless tires and makes it easy to set them up without any hassles. Low rolling resistance and a reduced risk of punctures add up to a better overall riding experience, especially on rugged terrain.

The wheels are engineered for the unique demands of disc brakes, built up with 24 straight-pull spokes, which are stronger than J-bend spokes. So wherever the road goes, and however rough it gets, you’re ready to keep things rolling.

---

Features – Allroad Rearwheel

• 22mm wide rim takes tire up to 62mm.
• UST Road Tubeless technology improves comfort and rolling resistance, and reduces the risk of punctures
• Compatible with all standard retention systems
• High-quality QRM cartridge bearings
• Disc-brake-specific, sleeved-style rim technology
• Straight-pull round spokes, which are stronger than J-bend spokes
• Sleeve joint rim minimizes weight
• Consistent and stable spoke lacing
• Low-friction hubs

Product features

• Use: Allroad / Gravel

• Model: Allroad
• Wheel size: 28″
• Rim type: Clincher
• Tubeless ready: Yes
• ETRTO: 622
• Brake type: Disc Brake
• Freehub system: Instant Drive 360
• Bearings: Auto adjust sealed cartridge bearings (QRM Auto)
• Freehub body: Shimano 9-/10-/11-speed
• Rim inner width: 23 mm
• Rim height: 22 mm
• Valve hole: Presta / SV Ø 6.5 mm
• Hub axle system: 12 x 142 mm TA
• Spoke type: straight pull, round
• Spokes: 24 (2-cross)
• Recommended tyre sizes: 28 mm to 62 mm (1.1″ to 2.5″)
• ASTM Catergory: 2 (road and offroad with jumps less than 15cm)
• Recommended system weight max: 120 kg (Rider + Bike + Equipment)

Material

• Rim: Aluminium
• Hub: Aluminum
• Freehub: Steel
• Spoke: Steel
• Nipples: Steel

Color

• black

Disc Brake mounting (choose variant)

• Disc 6 bolts
• Disc Centerlock

Weight (manufacturer information)

• 1020g

---

Scope of delivery

• 1 x Allroad Disc Rearwheel
• 1 x 9,5-mm-Reduzierstücke für Schnellspanner an Instant Drive 360-Naben
• 1 x Tubeless rim tape
• 1 x UST valve and accessories
• User guide

---

Technology

Instant Drive 360
The new Instant Drive 360 freewheel system is super light and fast to engage with only 9°. A large contactless rubber seal provides low friction, while a wide array of end caps makes it super versatile.
